CS-Series 4x10-inch Coaxial Speakers give you the quality you want, with the factory fit you need.
The CS-Series design features near-zero tweeter protrusion, so your speakers fit perfectly behind factory grilles. This simple, drop-in solution delivers acclaimed KICKER performance with a stamped-steel framework, rigid polypropylene cone and EVC™ (Extended Voice Coil) technology. You get superb clarity, durability and volume – now and way down the road!
These CS speakers work best with 75 watts of recommended power. See below for more details.
Fits nearly every car made that requires 4x10s, especially older GM models
Zero-protrusion tweeters to fit nearly any factory depth
Woofer EVC™ (Extended Voice Coil) tech assists with precise linear excursion
UV-treated poly-foam surround resists heat or direct sunlight
Large woofer magnet in a heavy-duty motor for ultra-clean bass
PEI-tweeter construction provides superb clarity
Neodymium tweeter magnets allow for increased volume in high frequencies
Speaker Design2 - wayWoofer Size [ in, mm ]4x10 [100x250]Tweeter Size [ in, mm ]1/2 [13]DC Resistance [ ohm ]3.3Peak Power [ watts, per ANSI/CTA-2031-A ]225Recommended Amplifier Power [ watts RMS ]75Sensitivity - SPLo [ dB @ 1W, 1m ]88Effective Frequency Range [ Hz ]45-20kMounting Hole Diameter [ in, mm ]3-7/8 x 9-5/8, 90 x 238
Top Mount Depth [ in, mm ]2-3/8, 80Bottom Mount Depth [ in, mm ]2, 50Tweeter Protrusion [ in, mm ]0GrillesNoTweeter Magnet MaterialNeodymiumTweeter Dome MateriaPEI [polyether imideTweeter DesignBalanced domeWoofer Cone MaterialPolypropyleneWoofer Surround MaterialPolyester foamWarrantyWhen purchased from an Authorized KICKER Dealer or kicker.com, KICKER warrants this product to be free from defects in material and workmanship under normal use for a period of TWO (2) YEARS from date of original purchase
